Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2- 16
J2/P2
Pin D C
1 GND GND
2 MEMCS16* SBHE*
3 IOCS16* LA23
4 IRQ10 LA22
5 IRQ11 LA21
6 IRQ12 LA20
7 IRQ15 LA19
8 IRQ14 LA18
9 DACK0* LA17
10 DRQ0 MEMR*
11 DACK5* MEMW*
12 DRQ5 SD8
13 DACK6* SD9
14 DRQ6 SD10
15 DACK7* SD11
16 DRQ7 SD12
17 +5V SD13
18 MASTER* SD14
19 GND SD15
20 GND GND/KEY
PCM-5895 Rev.B does not support PC/104 way legacy ISA-DMA mode
cause by AMD architecture.
