Owner manual

Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2-13
2.14 Fan Control Circuit Power Selection (JP18)
JP18 Function
1-2 +12V (Default)
2-3 +5V
2.15 FAN Connector (CN1)
Pin Signal
1 GND
2 +12V
3 FAN Sense
2.16 USB Port #1 and Port #2 (CN6)
Pin Signal Pin Signal
1 VDD0 2 GND
3 D0- 4 GND
5 D0+ 6 D1+
7 GND 8 D1-
9 GND 10 VDD1
2.17 Front Panel (CN7)
Pin Signal
1-2 ATX Power-on Button
3-4 HDD Active LED
5-6 External Speaker
