Chapter 2 Quick Installation Guide 2-7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
JP2 AT/ATX Power Type Selection
JP6 CFD Master/Slave Selection
JP7 Clear CMOS
JP8, JP10 COM Ports RI/+5V/+12V Selection
JP11 COM Ports +5V/+12V Selection
JP12 LCD Clock and Power Selection
JP13 Inverter Voltage Selection
JP14, JP15 CAN Bus Termination
JP16 PCI 104 Power Selection
JP17 Contrast IC Power Selection
JP18 Fan Control Circuit Power Selection
