Chapter 2 Quick Installation Guide 2-22
2.41 SIM Card Socket (CN28)
Pin
Signal
Pin
Signal
1
UIM_PWR
2
UIM_RST
3
UIM_CLK
4
Ground
5
UIM_VPP
6
UIM_DATA
2.42 CFast™ Disk (CFD1)
Pin
Signal
S1
Ground
S2
SATA_TX+
S3
SATA_TX-
S4
Ground
S5
SATA_RX-
S6
SATA_RX+
S7
Ground
P1
N/C
P2
Ground
P3
N/C
P4
N/C
P5
N/C
P6
N/C
P7
Ground
P8
CFD_LED#
P9
N/C
P10
N/C
P11
N/C
P12
N/C
