Chapter 2 Quick Installation Guide 2-17
3
Data4+
4
Ground
5
Ground
2.28 PS/2 Keyboard and Mouse (CN15)
Pin
Signal
Pin
Signal
1
Keyboard Data
2
Keyboard Clock
3
Ground
4
+5V
5
Mouse Data
6
Mouse Clock
2.29 Touch Screen I/F (CN16)
Pin
8-wire Signal
5-wire Signal
4-wire Signal
1
Ground
Ground
Ground
2
Top Excite
Top
UL(Y)
3
Bottom Excite
Bottom
UR(H)
4
Left Excite
Left
LL(L)
5
Right Excite
Right
LR(X)
6
Top Sense
N/C
SENSE
7
Bottom Sense
N/C
N/C
8
Left Sense
N/C
N/C
9
Right Sense
N/C
N/C
2.30 USB Port #3 (CN17)
Pin
Signal
1
+5V Standby
2
Data3-
3
Data3+
4
Ground
