Manual

SubCompact Board
G E N E - T C 0 5
Chapter 2 Quick Installation Guide 2-16
2.24 COM Port #4 (CN11)
Pin
Signal
Pin
Signal
1
DCDD
2
DSRD
3
RXD
4
RTSD
5
TXD
6
CTSD
7
DTRD
8
RID
9
Ground
2.25 COM Port #5 (CN12)
Pin
Signal
Pin
Signal
1
DCDE
2
DSRE
3
RXE
4
RTSE
5
TXE
6
CTSE
7
DTRE
8
RIE
9
Ground
2.26 COM Port #6 (CN13)
Pin
Signal
Pin
Signal
1
DCDF
2
DSRF
3
RXF
4
RTSF
5
TXF
6
CTSF
7
DTRF
8
RIF
9
Ground
2.27 USB Port #4 (CN14)
Pin
Signal
1
+5V Standby
2
Data4-
