LCD Display AGD-315D AGD-315D 15” XGA Rugged Touch Display On Screen Display Control IP-65 Front Bezel 5-wire Resistive Touch Screen AGD-315D Manual 1st Ed August 2011
LCD Display AGD-315D Copyright Notice This document is copyrighted, 2011. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable.
LCD Display AGD-315D Acknowledgments Intel® is registered trademarks of Intel® Corporation. IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation. Microsoft® Windows is a registered trademark of Microsoft® Corporation. RTL is a trademark of Realtek Semi-Conductor Co., Ltd. C&T is a trademark of Chips and Technologies, Inc. UMC is a trademark of United Microelectronics Corporation. ITE is a trademark of Integrated Technology Express, Inc.
LCD Display AGD-315D Packing List The LCD monitor comes with the following standard parts shown as below. Check and make sure they are included and in good condition. If anything is missing or damaged, contact the dealer immediately. 1 AGD-315D 1 Utility CD-ROM Contains User’s Manual (in PDF format), Drivers and Utilities 1 VGA Cable 1 USB Cable 1 RS-232 Cable If any of these items are missing or damaged, you should contact your distributor or sales representative immediately.
LCD Display AGD-315D Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. 4. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible. 5. Keep this equipment away from humidity. 6. Put this equipment on a reliable surface during installation.
LCD Display AGD-315D 14. If any of the following situations arises, get the equipment checked by service personnel: a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work according to the users manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage. 15.
LCD Display AGD-315D Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Display 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) × ○ ○ ○ ○ ○ × ○ ○ ○ ○ ○ 外壳 × ○ ○ ○ ○ ○ 液晶模块 × ○ ○ ○ ○ ○ 触控模块 × ○ ○ ○ ○ ○ 电源 × ○ ○ ○ ○ ○ 印刷电路板 及其电子组件 外部信号 连接器及线材 O：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 一、此产品所标示之环保使用期限，系指在一般正常使用状况下。 二、上述部件物质触控模块为选购品。 vi
LCD Display AGD-315D Contents Chapter 1 General Information 1.1 Introduction................................................................ 1-2 1.2 Features .................................................................... 1-3 1.3 General Specification ................................................ 1-4 1.4 Dimension ................................................................. 1-6 1.5 Waterproof Sponge Position ..................................... 1-8 Chapter 2 Hardware Installation 2.
LCD Display AGD-315D 3.4 Contrast/ Brightness- Submenu. ............................... 3-5 3.5 Geometry Menu......................................................... 3-6 3.6 Color Temperature- Submenu OSD Main Menu: Push The MENU Keys.............................................................. 3-7 3.7 RGB Color- Submenu. .............................................. 3-8 3.8 Language- Submenu................................................. 3-9 3.9 Auto Config- Submenu..................................
LCD Display AGD-315D Chapter 1 General Information Chapter 1 General Information 1-1
LCD Display AGD-315D 1.1 Introduction Thank you for purchasing of the Industry Display Panel TFT LCD monitor - a marvelous contribution of cutting-edge technology. The LCD monitor has been designed with serious thoughts to present the best performance for most applications. Symbol of elegance, its compact and slim profile are well suited in working locations where space is at a premium. The TFT LCD monitor displays sharper, more brilliant, crisper and flicker-free images.
LCD Display AGD-315D 1.
LCD Display AGD-315D 1.3 General Specification Type Color TFT Size 15" TFT LCD Construction IP-65 Aluminum Die Cast Front Bezel Mounting Panel/ VESA/ Wallmount Input signal VGA, DVI Control OSD (On Screen Display) on the rear panel Power Supply External power adapter Dimension AGD-315D 15.35” (W) x 12.74”(H) x 4.91”(D) (390mm x 323.5mm x 124.7mm) Cutout Size 14.8”(W) x 12.03”(H) (376mm x 305.5mm) Gross Weight 9 lb (4.1 Kg) Power Input : 9V~30V DC, 4~1.
LCD Display AGD-315D Display Modes Full Screen in 640x480, 800x600, 1024x768, 1280x1024 Modes Color 16.7M colors Touchscreen Type 5-wire resistive Resolution 2048 x 2048 Light 88 ± 2% (Pure) transmission Controller RS-232 & USB interface (optional) Environmental Operating 32°F~ 122°F (0°C to 50°C) temperature Vibration 1g rms/5-500Hz/random operation Shock 20 G peak acceleration (11 msec.
LCD Display 1.
LCD Display AGD-315D Chapter 1 General Information 1-7
LCD Display AGD-315D 1.5 Waterproof Sponge Position Inside sponge: A. Tear off the protection paper on the self-adhesive side of the inside sponge. B. Stick the sponge on the recessed area of the Aluminum bezel or customer’s own bezel.
LCD Display AGD-315D Chapter 2 Hardware Installation Chapter 2 Hardware Installation 2-1
LCD Display AGD-315D 2.1 Before Unpacking It is very important to place the LCD Display in a suitable environment. The surface for placing the LCD Display should be stable and level. Make sure the place has good ventilation, and out of direct sunlight; away form sources of excessive dust, dirt, heat, water, moisture and vibration. Convenience for connecting the LCD Display the related facilities should be well considered too.
LCD Display AGD-315D 2.2 Connecting Power To power on the LCD Display, use the provided AC-DC adapter and the power cord to connect to the power output socket of the monitor. Fasten the connector securely. A ”Surge Protection” device plugged between the AC-DC adapter and the wall outlet is recommended to prevent the effects of sudden current variations from reaching the LCD Display. The sudden peaks of electricity may harm the LCD Display.
LCD Display AGD-315D 2.3 Connecting to the Computer Turn off the computer and the LCD Display before connecting. Use the Monitor-to-PC VGA、DVI cable to connect the LCD Display to your computer. The cable heads are the same on either side. Fasten the connectors securely.
LCD Display AGD-315D 2.4 VGA Port Connector This DB-15 connector can be connected to the system via the external 15-pin DB-15 connector through the I/O from this unit. Pin Signal Pin Signal 1 Red 2 Green 3 Blue 4 N.C. 5 GND 6 GND 7 GND 8 GND 9 N.C. 10 GND 11 N.C.
LCD Display AGD-315D 2.5 DVI Port Connector Connecting a standard DVI-D connector through I/O port of this unit. This connector supports digital signals only Pin Signal Pin Signal 1 N.C. 2 TMDS Data 2+ 3 TMDS Data 2/4 shield 4 TMDS Data 4- 5 TMDS Data 4+ 6 DDC clock 7 DDC data 8 N.C.
LCD Display AGD-315D 2.6 Serial Port Connector For Touch Screen This pin definition of the connector will be referred when a touch screen has been installed. It must be connected to the RS-232 port of the PC. The touch screen cable is included with all orders which include the optional RS-232 Touch Screen.
LCD Display AGD-315D 2.7 Mini USB Connector For Touch Screen This pin definition of the connector will be referred when a touch screen has been installed. It must be connected to the Mini USB port of the PC. The touch screen cable is included with all orders which include the optional Mini USB Touch Screen. Pin Signal Pin Signal 1 +5V 2 DATA (-) 3 DATA (+) 4 N.C.
LCD Display AGD-315D 2.8 Panel Mounting This LCD Display can be placed on a shelf or table, or mounted onto the wall. To mount it onto the wall, you need the mounting brackets, which you will find them in the accessory box.
LCD Display AGD-315D AGD-315D series can be mounted to the industrial standard 15" rack directly. There are four screw holes on each side of the panel.
LCD Display AGD-315D 2.9 Easy Stand, Swing-ARM Mounting The AGD-315D series can be mounted in different ways. You can place the desktop stand for desktop use or attach it on a swing-arm bracket. Easy Stand The brackets of easy stand are attached to the rear of AGD-315D. First of all, loosen the screw of point A. Then, unscrew the screw of point B. Pull down the bracket and use the screw got from point A to fasten the bracket in point B. There should be no screw in point A.
LCD Display AGD-315D 2.10 VESA Wall Mounting Mounting the LCD Display with UL Listed Wallmount Bracket only. The LCD Display can be mounted on a monitor arm or wallmount plate. Caution: When mounting the LCD Display, take care to tighten the retention screws or bolts until fully secured, but do not over tighten. Over tighting the retention screws or bolts may cause them to become stripped, rendering them useless.
LCD Display AGD-315D VESA Mounting Holes To mount the LCD Display onto a monitor arm or wallmount plate, please follow the steps below. Step 1: Line up the threaded holes on the monitor rear panel with the screw holes on the monitor arm or wallmount plate. Step 2: Secure the monitor to the arm or stand with the retention screws supplied with the monitor arm or stand.
LCD Display AGD-315D Chapter 3 On Screen Display Control Chapter 3 On Screen Display Control 3-1
LCD Display AGD-315D 3.1 On Screen Display (OSD) Board Description Buttons Description Turn the monitor power ON or OFF. Activate the OSD menu. Enter/confirm the selected option. Move the selector to the next option. UP / Right / Increase / Increase the gauge value of the Input select selected option. Power Menu / Enter Down/ Left / Decrease Change input source. Move the selector to the previous option. Decrease the gauge value of the selected option.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D 3.
LCD Display AGD-315D Chapter 4 Touch Screen Driver Installation Chapter 4 Touch Screen Driver Installation 4-1
LCD Display AGD-315D 4.1 Introduction The optional AGD-315D Series touch screen uses 5-wire resistive technology to provide more accurate sensing capacity than other technologies. The touch screen is specially designed for tough industrial environments, and has been approved by FCC Class A standards. Note: For A1 version, if you connect the RS-232 and USB touch screen interfaces to the system simultaneously, the USB mode will be the priority. For A2 version, the connection will be switched by software.
LCD Display AGD-315D Serial Interface • EIA 232E (Serial RS-232), DCE configuration. 8 Data Bits, 1 Stop Bit, No Parity, Full Duplex. • Hardware handshaking: RTS/CTS. • DSR is pulled HIGH (>+3V) by the touch screen control board when connected and powered. DTR can be asserted by the host to interrupt the flow of data from the controller.
LCD Display AGD-315D Operating Modes Full Touch Smart Set protocol. Emulation of E281A-4002 protocol can be selected by Smart Set command. Initial/ Stream/ Un touch/ Z-axis Enable Modes. Touch Resolution: 2048 x 2048, size independent. Conversion Time: Approximately 20 ms per coordinate set.
LCD Display AGD-315D 4.2 Resistive Touch screen Driver Installation Hardware Touch screen controllers must be configured for the driver prior to installation. EETI typically ships controllers in a default setup that is compatible with this driver.
LCD Display AGD-315D HID drivers that provide low-level support for EETI touch screen controller. An EETI touch monitor with a USB touch screen controller installed will provide the following limited operation with these native HID drivers.
LCD Display AGD-315D 4.3 Installing Driver for Windows® XP/ Windows® 7 / Linux The touch screen has drivers for Windows® XP、 Windows® 7 and Linux . You should read the instructions in this chapter carefully before you attempt installation. Note 1: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen.
LCD Display AGD-315D 2. Click the “Next” button on the screen 3. Click on the “Finish” button and restart your system Single monitor, Serial Port controller The driver files will install automatically. When the "Setup Complete" screen appears, you may choose to run calibration immediately or later. If you choose not to run this program now, you can run it from the EETI Control Panel application.
LCD Display AGD-315D 1. Executing eGalax on Desktop 2.
LCD Display AGD-315D 3. Choose Tools to calibrate 4. Click on 4 Points Calibration to execute calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate.
LCD Display AGD-315D For Windows® 7 OS please execute: CD-ROM: \\TouchScreen-DRV\eGalax Touch \Win 7 \Setup.exe 1. Click on the “Next” button 2.
LCD Display AGD-315D 3. Tick “None” if the system did not start 4 points calibrating after reboot. Click on the “Next” button. 4.
LCD Display AGD-315D 5. Select Destination Folder, and click on the “Next” button 6. Click on the “Next” button Single monitor, Serial Port controller The driver files will install automatically. When the "Setup Complete" screen appears, you may choose to run calibration immediately or later. If you choose not to run this program now, you can run it from the EETI Control Panel application.
LCD Display AGD-315D 1. Executing eGalax on Desktop 2.
LCD Display AGD-315D 3. Choose Tools to run calibration 4. Click on 4 Points Calibration to execute calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate.
LCD Display AGD-315D For Linux Fedora 14 kernel 2.6.35.6-45.fc14 OS please execute: CD-ROM: \\TouchScreen-DRV\eGalax Touch \Linux\eGalaxTouch 32 1. Open System Input Command (su) and System Password 2.
LCD Display AGD-315D 3. Input command ( cp /root/xorg.conf.new /etc/X11/xorg.conf) 4.
LCD Display 5. Executive Touch Driver 6.
LCD Display AGD-315D 7. Select the “ 3 ” USB interface. (Select the USB interface and press “Enter” key of the keyboard to start the installation) 8.
LCD Display AGD-315D 9. Reboot the system to activate the changes 10.
LCD Display AGD-315D 11. Select “eGalax Touch32_Version1.1-2.6X” Folder 12.
LCD Display AGD-315D 13. Click on the “eGalax Touch” to calibrate immediately 14.
LCD Display AGD-315D 15. Execute 4 Points Calibration Note: If the alignments do not match display by 4 Points Calibration, please use 9 Ports or more to calibrate. 16.
LCD Display AGD-315D 17. If you are going to replace the Interface, please remove the old Touch Driver (Input command: sh setup.sh uninstall) 18.
