Oscar Mouse Editor Software (Tailor-made to Dominate the Play) User’s Guide Model: XL-771K, XL-755K, XL-740K, XL-730K, XL-750MK, XL-750BK, X-748K, X-738K, X-718K, X-710MK, X-710BK, X-705K, X-755K www.a4tech.
Installing "Oscar Mouse Editor Software (Note: The driver is applicable to Windows 2000, XP, XP (x64), 2003(x64) and VISTA x86) A. Before installing the mouse‘s Oscar software, uninstall other mouse’s Oscar software. B. Insert the enclosed Oscar software (CD) to start installation. C. Follow the on-screen steps to finish software installation. D. The Oscar icon “ ” will appear on your desktop, then you have successfully installed the Oscar software. OR Go to START, and then select PROGRAM.
How to Use the Oscar Mouse Editor Software Customizing the buttons on the mouse in “Optional Macro”, Please follow the steps: Step 1: Opening the Main Menu of Oscar Mouse Editor Software Just double-Click on the “Oscar Editor” icon“ ”on the desktop. OR Go to START >> PROGRAM >> Select Oscar Editor. Now the Oscar “Main Menu” will pop up as shown on the right. Step 2: Now, you can start to program each button of the mouse.
Before we proceed further, it is recommended that you understand the term “Script” so that you can maximize the use of powerful Oscar software. Script is a special file format used within the Oscar software. After the command script is compiled, it can be saved in a script file, and store directly in mouse on-board memory. Thus, the mouse is transform to a special script mouse with each button being tailor-made.
Illustrating the Available Settings for Each Button Click any button option on the “Oscar Main Menu”, you’ll see the below available tasks of “Task Menu” for each button. Task Functions Optional Macro Pull-down Available tasks No setting System default or no function is selected Keyboard Any key or any collective key on the keyboard Mouse Left Button, Right Button, Middle Button, 4th Button, 5th Button, Up, Down, Leftwards, Rightwards.
16-in-1 Mouse gestures are simple symbols that you "draw" on your screen using your Mouse Gestures mouse. When you perform a mouse gesture, it will perform one of the 16 ”actions” that is associated with that gesture. In short, it's a nifty little program that lets you easily control programs by drawing symbols with the mouse.
Knowing Main Function of the “Macro Manager” Click the any button option of “Oscar Main Menu”, select the” Macro Manager…”from the “Task Pull-down Menu”. Logic Command Area Record K/B and Mouse Actions Advanced logic commands (such as: loop, skip a line, if, equal to, interval It will duplicate your mouse and keyboard repeat, jump… etc.
Illustration and Usage of “Macro Manager Menu” A． Macro Programming Area You can edit the macro details on the “Macro Programming Area”. You may input the commands by moving the mouse and click on the mouse/ keyboard illustration boards as Macro shown to the left and to the bottom. Each action you take Programming will be recorded immediately and be printed on the “Macro Programming Area”.
performed while the key is pressed, it will stop till another key is pressed again. D. Record K/B and Mouse Actions There is another handy and useful way to edit the macro commands. By simply enabling the “Record Mouse and Keyboard action” from the “Macro Manager Menu”, you will be able to “duplicate” each actual action you apply to the mouse or to the keyboard and the corresponding commands delimited with proper time interval is being recorded and be printed out synchronously.
In the Mouse area, there is absolute coordinate icon , click and drag the icon will capture the absolute position (X, Y) of target and then the value will be shown in the mouse absolute coordinate.
Select “Tilt wheel setting” to set numbers of line at a time of Select “Switch Responding Time” to set mouse key responding horizontal scrolling. time between 3-30ms. It not only extends the mouse key switch lifetime but also offers quick response over your opponents during the game play Select “Report Rate Setting” to speed mouse’s acceleration up Select “Key Hint Setting” to annotate the function name for each to 1000Hz, and allows you to adjust the mouse’s report rate.
DPI 6: 3600DPI Yellow & Green Extra High-Speed and pinpoint accuracy required player 1280×1024 Click the “DPI Setting” Button to quickly shift and indicate from 600, 800, 1200, 1600, 2000 to as high as 3600 DPI.
1. By default setting, just click the “DPI Setting Button” on the mouse to change the DPI for range of 600-800-1200-1600-2000-3600 DPI, and the “DPI Setting Button”indicator color will be changed in the sequence as shown on the above “Indicator Color”. 2. You may customize your own DPI range and sensibility with Oscar software. Double click on the Oscar icon from the task bar, the main menu will be shown as right. >>Select the “Script Name” you want to change the DPI, and then: A.
Step 3: Tick the box of “Add delay automatically while press" >>Select ”mSec” of time unit in the “Time unit” Step 4: Input”64” of time value in “Time” box. >>Click “Left Button” on “Mouse Simulation Area”. Step 5: Input”200” of time value in “Time” box. >>Click “Left Button” on “Mouse Simulation Area”. >>Delete "Press _Left Button" and "Release _Left Button". Step 6: Repeating steps from 4 to 5, now your editing area will look like this as figure 1 shows. Step 7: Click the icon to save the settings Fig.
Step 2: Tick the box of “Add delay automatically while press “and “Add delay automatically while release”. >>Select ”mSec” of time unit in the “Time unit”. Step 3: Input”64” of time value in “Time” box. >>Click “Left Button” on “Mouse Simulation Area”. Step 4: Input”70” of time value in “Time” box. >>Click “Left Button” on "Mouse Simulation Area" Step 5: Input”85” of time value in “Time” box. >>Click “Left Button” on "Mouse Simulation Area" Step 6: Input ”95” of time value in “Time” box.
Step 2: Input ”799” of coordinate value in “Mouse Relative Coordinate X Axis Box”. >>Click “Plug In”. Step 3: Select ”mSec” of time unit in the “Time unit” >> Input”23” of time value in “Time” box. >>Click “Plug In”. Step 4: Repeating three times from step 2 to step 3. Step 5：Input ”500” of coordinate value in “Mouse Relative Coordinate X Axis Box”. >>Click “Plug In”.
Step 1: From the “Oscar Main Menu”, select “Macro Manager” from the Task Pull-down Menu” of designated mouse button, then you'll see "Macro Manager Menu" pop up. Macro Manager Menu Oscar Main Menu Step 2: Click the “Non Recycle Macro” of the “Macro Manager Menu”. >>Select “Recycle macro”>>Select “Press to start, Release to stop”. Step 3: Tick the box of “Add delay automatically while release" >>Select ”mSec” of time unit in the “Time unit”. >> Input ”110” of time value in “Time” box.
while the designated mouse button is released. Example 5：In “CS” game, 1 Click to Buy All Weapons and Accessories Step 1: From the “Oscar Main Menu”, select “Macro Manager” from the Task Pull-down Menu” of designated mouse button, then you'll see " Macro Manager Menu" pop up. Macro Manager Menu Oscar Main Menu Step 2: Tick the box of “Add delay automatically while press “and “Add delay automatically while release”. >>Select ”mSec” of time unit in the “Time unit”. >> Input ”20” of time value in “Time” box.
Example 6： Quick perform settings in the “PROE2001” This example requires initial setup in the three parts, respectively they are computer settings, PROE software settings and Oscar mouse editor software settings. Step 1: Computer Settings Open "My Computer", on the hard drive D create a new folder "D:\WORK" >>Press "Right Button" of the mouse on "PROE" shortcuts icon >> select "Properties" Step 2: PROE Software Settings: Open "PROE" software; create a new file under the path that you appointed.
Example 7： Except “Scroll up” and “Scroll Down” button options, any button options can be customized to have up to 16 functions at the same time, such as “Zoom In, Zoom Out, Scroll Left, Scroll Right, Copy /Paste, Previous Page, Next Page…etc.”- All at your fingertip. Operation Procedure Step 1: Double click on the “Oscar Editor” icon“ ”on the desktop. OR Go to START >> PROGRAM >> Select Oscar Editor. Now the Oscar “Main Menu” will pop up as shown below.
Available Mouse Gesture list: For the mouse gestures, there are total 16 functions available and ready for option. And among them, 8 of simple gestures are specially designed to offer user-definable sensitivity. For instance, you may define the 8 simple gestures on the “wheel button” with the functions as shown below, then just press the “wheel button” and move the mouse to draw the line as the arrow shows on your screen, then that function will be executed instantly.
Knowing the Oscar Gaming Mouse Speed mouse report time up to 1ms with Full-speed USB Adjustable Mouse Key Response Time You can set mouse key responding time between 3-30ms. It not Designed with extreme fast report time up to 1ms with only extends the mouse key switch lifetime but also offers quick Full-speed USB (Maximum 1000Hz reports/sec), The Mouse response over your opponents during the game play allows you to fight 4x4 times faster than the normal USB mouse.
Model: XL-771K In the game-play, one click on the button, 3 bullets will be shot sequentially and your target is destroyed in the seconds.
Model: XL-755K extra 6 DPI-Shift Ability with LED convenience while browsing a wide Color Indicator (Default DPI page with Modes：600 - 800 - 1200 - 1600 - Tilt-Wheel: It provides “Leftwards” and “Rightwards” scrolling functionality.
Model: XL-730K 6 DPI-Shift Ability with LED Color Indicator (Default DPI Modes：600 - 800 1200 - 1600 - 2000 - 3600 DPI) After installing Oscar software, Click the Forward Backwar customizable “DPI Button” with Color Indicator” instantly shifts multiple sensitivity levels between 100 - 3600 dpi. The mouse gives you quick access from In the game-play, one click on the button, 3 bullets will be shot sequentially and your target is destroyed in the seconds.
Specifications Oscar Laser Gaming Mouse MODEL: XL-755K, XL-740K, XL-730K, Oscar Optical Gaming Mouse MODEL: X-738K,X-718BK,X-748K Oscar Optical Gaming Mouse MODEL: X-755K, X-710K, X-710BK, XL-750K, XL-750BK, XL-750MK, XL-771K, X-710MK, X-705K XL-770K,XL-83K,XL-85K 3,600 DPI X7 Laser Engine 3,200 DPI X7 Optical Engine 2,000 DPI X7 Optical Engine • Key Response Time (3X Fire Button、Left • Key Response Time (3X Fire Button, Left • Key Response Time (3X Fire Button, Left & & Right Button): 3-30ms &
z Consult the dealer or an experienced radio/TV technician for help. THE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
