High speed Optical Mouse User’s Manual Model: X-708 www.a4tech.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TOTHE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Federal Communications Commission Requirements The equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to part 15 of the FCC Rules.
STEP ONE: HOW TO INSTALL X7-WORKS SOFTWARE ***** For Windows Me / 2000 / 2003 / XP 1. 2. 3. 4. 5. 6. 7. 8. MUST: Please uninstall any previous mouse driver before installing the X7Works MUST: Make sure you have completely finished setting up your Mouse Properties Window mouse pad and mouse Insert the included Compact Disc (CD) into your CD-ROM Click “Install Driver”.
STEP TWO: HOW TO PROGRAM YOUR MOUSE BUTTONS l Open your Mouse Properties. First Tab: Section I: 1. Button Button Assignment The mouse image that appears in the first section is a key to numbers listed to the right. For example, button #1 has been assigned as “Main Button” by default and it’s not programmable. 2. The rest of the buttons from #2 to # 6 are programmable.
STEP THREE: HOW TO SET X7-JUMP FUNCTION ( LEARN TO SIMULATE KEYBOARD’S COMMANDS AND PROGRAM XY SENSITIVITY INDEPENDENTLY) The function X7-work not only provides program XY sensitivity independently , but also can be set in any of the buttons from # 2 to # 6 of simulation functions for the keyboard and half of the mouse button simulation functions for the keyboard. th By default, the 6 Button has been preset as the function “X7-Jump”.
Section II: Keystrokes To ADD keystrokes: Click on the button “New Keystroke” and you’ll see a “Keystroke” Window pops up (Image: left, bottom) Here you will see 3 radio buttons: l Press and hold will input keystrokes consecutively l Press and hold will only input once the keystrokes l Press will input keystrokes consecutively, press again will release the keystrokes st If you select the 1 radio button, it means you would like to have the mouse completely simulate the keyboard’s keystroke – when y
Example 1: st Select 1 Radio Button 1. Click on “Record” (Reference: 2. Press “R” on the Keyboard 3. Click “OK” 4. It will bring you back to previous page 5. Now click on “Keystroke (R)”, the one you just created 6. Select the Mouse Button (green icon) on the Mouse Image to your right to Image A) store the “Keystroke (R)”. (Image A) 7. Green icon will turn red once it’s been selected. (Image B) 8. Click “Apply” >> “OK” We have stored it in Mouse Button # 3.
Example 2: st Select 1 Radio Button 1. Click on “Ctrl+A” (Reference: Image C) 2. Press “Ctrl+A” on the Keyboard 3. Click “OK” 4. It will bring you back to previous page 5. Now click on “Keystroke (Ctrl+A)”, the one you just created 6. Select the Mouse Button (green icon) on the Mouse Image to your right to store the “Keystroke (Ctrl+A)”. (Image C) 7. Green icon will turn red once it’s been selected. (Image D) 8. Click “Apply” >> “OK” We have stored it in Mouse Button # 4.
Example 3: nd Select 2 Radio Button 1. Click on “Record” 2. Press “A4TECH” on the Keyboard 3. Click “OK” 4. It will bring you back to previous page 5. Now click on “Keystroke(A4TECH)”, the one you just created 6. Select the Mouse Button (green icon) on the Mouse Image to your right to (Image E) store the “Keystroke (A4TECH)”. (Image E) 7. Green icon will turn red once it’s been selected. 8. Click “Apply”, then “OK” (Image F) We have stored it in Mouse Button # 5.
Example 4: rd Select 3 Radio Button 1. Click on “Record” 2. Press “Z the Keyboard (Image G) 3. Click “Stop” to stop recording >> then click “OK” 4. It will bring you back to previous page (Image F) 5. Now click on “Keystroke(Z)”, the one you just created 6. Select the Mouse Button (green icon) on the Mouse Image to your right to store the “Keystroke(Z)”. Image G 7. Green icon will turn red once it’s been selected. (Image H) 8. Click “OK” We have stored it in Mouse Button # 6.
TECH SUPPORT For tech support, please visit our website at www.a4tech.com or email us at support@a4tech.com WARRANTY All A4 Tech products come with 2 years limited warranty.
