11 Technical specification
2 x DVB-T TERRESTRIAL RECEIVER
Frequency range 47-862 MHz
Connector Type F female, 75 ohm
Input level range Nom. 35 – 75 dBµV
Bandwidth 7/8 MHz
Number of tuners 2
3 x MPEG DECODER – VIDEO - AUDIO
Video standard MPEG2 MP@ML, MPEG4
H.264 AVC
Audio standard AAC HE or MPEG1
Layer II AC-3 (option)
Aspect ratio Letterbox, Anamorphic,
Teletext Insertion in VBI
Subtitling Teletext or DVB subtitling
3 x MODULATOR
Modulation standard PAL B/G, I, D/K (DSB)
Audio FM-mono, NICAM stereo
A2 or A2*
Output channels 160 to 862 MHz
Pre-selected:
S11, S13, S15
Output level typ. 80 dBuV, fixed
Loop-through 47 - 862 MHz
Selectable On/Off
Built-in aerial amplifier 5 dB
RF output connector Type F female, 75 ohm
DECRYPTION
Decryption interface Common Interface
(PMCIA 5VDC)
Decryption type Single or Multidecryption CAM’s supported
OTHERS
AC Power supply 230 VAC typ (94-264 VAC)
AC Power consumption Typ. 18 W
DC output power 12 VDC +/- 10%
DC power consumption Typ. 15 W
Size 301x215x53mm (excl. connectors)
Weight approx. 900 g
Operating temperature -20 to +45°C
We reserve the right to technical changes without prior notice.
