Dimensions Guide
TECHNICAL SPECIFICATIONS
A
2
COMPOSITE
www.a2bath.com
6036CTSM2
60 x 36 x 82
inches
D
W
15"
76"
60"
C
B
A
12 ½"
41"
56"
30"
Shelf Space
Top: 4" x 12 ¾"
Mid: 4" x 13 ¾"
Bottom: 3" x 26 ½"
12 ½"
7
15
/
16
"
59 ½"
Rev. 08.24.18
FRAMING DIMENSIONS inches
Type
D
Depth
W
Width
H
Height
A B C
Alcove 37
1
⁄4 60 83
3
⁄8 Box Out 2 17
3
⁄8
SUMP DATA
Top of Drain to
Bottom of Overflow
Capacity
to Overflow
gal
WIDTH @ centerline DEPTH @ centerline
Top Bottom Top Bottom
12
5
⁄8 52 50
1
⁄2 42
5
⁄8 27
3
⁄8 22
3
⁄8
DIMENSIONS
Specifications
inches
Width: Overall / Net
60
Depth: Overall / Net 37
1
⁄4 / 36
Height: Overall / Net 83
3
⁄8 / 82
Enclosure Opening 56
Skirt Height 21
Drain Rough-In (from Back Wall) 17
3
⁄8
Drain Rough-In (from Side Wall) 2
Drain: Diameter / Clearance 2 / 3
1
⁄2
FEATURES Dimensional Tolerance ±
3
⁄8”.Dimensions needed for site preparation should be measured from the unit.Manufacturer assumes no responsibility for preparatory work.
Model # Material Jets Motor Controls Drain
Net Wt.
lbs
Pkg. Wt.
lbs
Tub-Shower #6036CTSM2 A
2
Composite – – – LH or RH 158 173
1
3
⁄
8
"
12
1
⁄
2
"
59
1
⁄
2
"
21"
17
3
⁄
8
"
8
1
⁄
2
"
60"
36"
1
1
⁄
4
"
56"2"
36"
7
7
⁄
8
"
Shelf Space
Top: 4" x 12 ¾"
Bottom: 4" x 13 ¾"
