Dimensions Guide

TECHNICAL SPECIFICATIONS
A
2
COMPOSITE
www.a2bath.com
FRAMING DIMENSIONS inches
Type
D
Depth
W
Width
H
Height
A B C
Alcove 31
1
⁄4 60 77
3
⁄8 Box Out 2
7
⁄8 14
1
⁄2
D
W
15"
76"
60"
C
B
A
12 ½"
41"
56"
30"
Shelf Space
Top: 4" x 12 ¾"
Mid: 4" x 13 ¾"
Bottom: 3" x 26 ½"
12 ½"
7
15
/ 16 "
59 ½"
6030CTS
60 x 30 x 76
inches
D
W
15"
76"
60"
C
B
A
12 ½"
41"
56"
30"
Shelf Space
Top: 4" x 12 ¾"
Mid: 4" x 13 ¾"
Bottom: 3" x 26 ½"
12 ½"
7
15
/ 16 "
59 ½"
SUMP DATA
Top of Drain to
Bottom of Overflow
Capacity
to Overflow
gal
WIDTH @ centerline DEPTH @ centerline
Top Bottom Top Bottom
9
7
⁄8 37 51
1
⁄2 45
1
⁄2 22
1
⁄4 20
1
⁄2
DIMENSIONS
Specifications
inches
Width: Overall / Net
60
Depth: Overall / Net 31
1
⁄4 / 30
Height: Overall / Net 77
3
⁄8 / 76
Enclosure Opening 56
Skirt Height 15
Drain Rough-In (from Back Wall) 14
1
⁄4
Drain Rough-In (from Side Wall) 2
7
⁄8
Drain: Diameter / Clearance 2 /
1
⁄2
FEATURES Dimensional Tolerance ±
3
⁄8”.Dimensions needed for site preparation should be measured from the unit.Manufacturer assumes no responsibility for preparatory work.
Model # Material Jets Motor Controls Drain
Net Wt.
lbs
Pkg. Wt.
lbs
Tub-Shower #6030CTS A
2
Composite – – – LH or RH 130 145
