User's Manual

— 3 —
To check the battery power, right-click the mouse icon in the Taskbar.
Choose the “Check RF-Mouse Status” option to display the RF-Mouse Status
window. The current battery percentage charge is shown.
Installing the Mouse Software
Before you can take advantage of the many features your mouse offers, you must install the driver. The driver is on the installation diskette that came packaged with your mouse.
Windows 95/98/2000/NT4.0 installation
1. Connect the mouse to your computer.
2. Insert the installation diskette into your floppy disk drive.
3. Click the Start button and then click Run.
4. In the Run dialog window, type A:\setup, where “A” is the letter of your floppy disk drive.
5. Click OK and follow the instructions on your screen to complete the installation.
The RF-Mouse ID code
Each RF-Mouse is assigned a unique ID code at manufacture, so the receiver only picks up the signal from your mouse and prevents other RF-Mouse radio signals from operating on
your computer. This feature can also be disabled, allowing other RF-pointing devices to operate your computer.
Connecting the RF-Mouse ID Code
When the driver installation is finished your computer reboots and the RF-
Mouse window (shown on the right) appears.
CONNECT ID:
Move the RF-Mouse for a few seconds to establish a
connection, then click
Connect ID. The unique ID code of your mouse is
recognized and another RF pointing device will not function on your computer.
Exit:
Click Exit if no other RF pointing devices are within 3 meters range or if
you want other RF pointing devices to be able to access your computer.
Changing the RF-Mouse ID Code
You can use a new RF-Mouse on your computer without changing the Radio receiver; you just need to change the ID code. Refer to the following:
1.
Press [Shift + Alt + F11] or [Shift + Alt + F12] to call up the RF-Mouse ID Code window.
2.
Move the RF-Mouse for a few seconds to establish a connection, then click Connect ID.
3.
The new ID code is Connected and the RF-Mouse window closes.
4.
Click Exit to close the RF-Mouse ID code window.
Identifying Components
The mouse is designed to fit snugly into your hand. The scroll wheel is positioned on the top allowing for easy
operation with the index finger. Standard mouse buttons are positioned to either side of the scroll wheels and can be
reached comfortably with the index and ring fingers. A third button is placed under the vertical wheel and can be
easily clicked by pushing down on the wheel.
The following pages will tell you how to configure the scroll wheels and buttons to suit your specific needs.
Cleaning the Mouse
Clean the mouse regularly to ensure efficient operation. Refer to the following:
1. Rotate the housing cover counterclockwise until it unlocks and remove it.
2. Remove the tracking ball.
3. Wash the tracking ball with warm water and soap then allow it to dry.
4. Use a cotton swab and alcohol to clean the tracking rollers in the housing.
5. Replace the tracking ball and the housing cover.
6. Rotate the housing cover clockwise until it locks in place.
