RE012
VoIP upload test success rate
Measures VoIP (MOS) upload completion
rate.
%
Quality
QUAP001
FTP downlink throughput
Measures downlink throughput in an
FTP file transfer. Measures downlink
throughput in an FTP file transfer.
Mbit/s
QUAP002
FTP uplink throughput
Measures uplink throughput in an
FTP file transfer. Measures uplink
throughput in an FTP file transfer.
Mbit/s
QUAP005
Listening voice quality (MOS),
downlink
MOS (Mean Opinion Score) value of a VoIP
downlink test.
MOS
QUAP006
Listening voice quality (MOS),
uplink
MOS (Mean Opinion Score) value of a VoIP
uplink test.
MOS
QUAP007
HTTP downlink throughput
Measures downlink throughput in an HTTP
document transfer. The test measures both
the time of the transfer and the size of the
document, from which the throughput in
Mbit/s is calculated.Measures downlink
throughput in an HTTP document transfer.
The test measures both the time of the
transfer and the size of the document, from
which the throughput in Mbit/s is
calculated.
Mbit/s
QUAP011
FTP downlink throughput of E2E
maximum
Measured throughput divided by the
theoretical maximum throughput that is a
function of measured SNR.
QUAP012
FTP uplink throughput of E2E
maximum
Measured throughput divided by the
theoretical maximum throughput that is a
function of measured SNR.
%
QUAP013
Jitter in VoIP test
The variation of delay (jitter) during a VoIP
test.
ms
QUAP015
Packet loss, VoIP test
Packet loss during a VoIP test.
%
QUAP019
Average of used QoS categories
in FTP
The average of all the used QoS-categories
during FTP transfer tests.
QUAP022
Average of requested QoS
category in VoIP
The average of all the requested QoS-
categories for VoIP test.
QUAP025
Average of used QoS categories
in VoIP
The average of all the used QoS-categories
during VoIP tests.
QUAP028
Average of requested QoS
category in HTTP
The average of all the requested QoS-
categories for HTTP transfer test.
QUAP031
Average of used QoS categories
in HTTP
The average of all the used QoS-categories
during HTTP transfer tests.
