The Network tab contains the highest number of KPIs of all tabs. Therefore check-boxes are
added to enable control of visibility. Both top-horizontal and vertical check-boxes control the
same set of KPIs. Even when the horizontal selection limits the number of KPIs, the user
benefits from the vertical control as well.
“Expand all” is there to show all KPIs at once.
