User Guide

3M-Matic
™
L-Clip Applicator S-867...
increases productivity, reduces operating expense
Manually sealing non-RSC style boxes
may add time and effort to packaging
operations. These case styles include
five panel folds, full overlap,
telescoping, and tuck fold.
The 3M-Matic
™
L-Clip Applicator
S-867 provides a cost-effective,
time-saving solution by applying L-clips
of tape securely and with less effort.
Semi-automatic unit applies pre-fed
4.5" L-clips of Scotch
®
Filament
Tapes and Scotch
®
Box Sealing Tapes
at up to 50 clips per minute. This
innovative process eliminates the set
time and waste of water-activated tape
and the sharp points of staples.
Full pneumatic operation with no
electric power needed.
Features include:
• Air pressure and flow controls
optimally positioned to reduce
unnecessary operator adjustments,
improve ease of maintenance access,
and add floor layout versatility
• Ability to position taping heads
closer together to apply clips as
close as 8" apart
• Oil-less operation to reduce
maintenance
• Wide selection of tape widths:
9mm, 12mm, 15mm, 18mm,
24mm, and 36mm.
Easy and intuitive to use, the 3M-Matic
Applicator S-867 makes consistent
corner closures quickly and efficiently
with minimal operator training.
Consistent tape length
• Conserves tape with
virtually no waste
Easy versatile placement
• Small footprint of only 31" x 29"x 11"
Access cover
• Easy open access for tape threading
• Automatically shuts off air pressure
when opened
Industrial-duty construction
• Heavy-duty one-piece steel frame
• Tough powder-epoxy coating paint
Optional single
head stand
• For mounting
and case handling
Length: 2.25" to unlimited
Width: 5" to unlimited
Height: 2.25" to unlimited
Box capacities
2
