Owner manual

Instant Replay Owner’s Manual page 37

• Enter a Destination Receiver Name using the HOT-KEYS as Alphanumeric keys

The name specified as the destination machine may end with a single asterisk character (HOT-

KEY 40) to indicate that all receivers partially matching the name should receive the transfer.

For example, EDITBAY* will transfer to Receivers named EDITBAY 1, EDITBAY 2,

EDITBAY 3, etc.

A single asterisk in the Destination Name will send to all Receivers regardless of their

Receiver Name.

To return to (NONE SPECIFIED) after using a specific name, simply edit the name and

delete all the characters using the BACKSPACE key (HOT-KEY 50), and press ENTER.

• Press ENTER to confirm Destination Receiver name, or CANCEL to restore the

previously entered name.

• Press the SCROLL UP ARROW key to proceed. Depending on which type of destination

was most recently selected, the display shows:

DESTINATION LOCATION DESTINATION LOCATION

MAIL BOX OR 1.0001 (SELECTED CUT)

• Press the SCROLL UP ARROW key to proceed.

• Change the Destination Location by pressing ENTER, followed by a SCROLL ARROW

key, to select between a specific location and MAIL BOX. The selection flashes until

you press ENTER again to confirm.

When a specific location is displayed, pressing ENTER allows selection of a different location.

Portions of the location field that are not applicable for a particular type of transfer are

displayed as X's:

1 . 0 0 0 1

(FOR TRANSFER OF A SINGLE CUT)

DRIVE DIRECTORY INDEX NUMBER

1 . 0 X X X

(FOR TRANSFER OF ALL CUTS)

The numeric keys of the keyboard are used to enter digit numbers. The left and right arrows

select a digit to edit, skipping over non-editable columns. Press ENTER at the edit prompt to

complete selection of the destination location.

Note that the Drive number must be left at '1' and the Directory number at '0' when sending to

other Instant Replay machines. Transmissions cannot be directed to the External drive.

However, when sending to machines such as the DigiCart/II which support multiple Drives

and Directories, the Drive and Directory numbers may be changed.

• Press the SCROLL UP ARROW. The display will show:

BEGIN TRANSFER
