Owner manual

Instant Replay Owner’s Manual page 21
• Press the desired HOT-KEY.
• Repeat to assign another, or press ASSIGN HOTKEY to end.
To Select A New Bank
• Press the BANK SELECT button.
• Press a HOT-KEY from 1 to 10 to select the desired Bank Number,
OR
• Use the SCROLL ARROWS to select the desired Bank.
• Press ENTER to confirm selection.
OR
• Press the BANK SELECT button to exit.
Note that the Bank Select operation will time out after a few seconds if no keys are pressed, and
return to the normal Cut display.
To Select the External or Internal Drive
• Press the BANK SELECT button.
• Press the “E” Key (HOT-KEY 13) to select the External Drive.
• Press the “I” Key (HOT-KEY 18) to select the Internal Drive.
Note that the EXTERNAL DRIVE item in the CONFIGURATION Menu must be ENABLED.
To Create and Edit a Playlist
• Press the PLAYLIST button.
• Press the HOT-KEY you wish to use as the first entry.
• Press additional HOT-KEYS for subsequent Playlist entries.
• When all entries have been made, press ENTER to conclude the list.
• Use the SCROLL ARROWS to scroll back to the START OF PLAYLIST.
• Press ENTER to change the Playlist type.
• Select MANUAL STEP or FOLLOW ON using the SCROLL ARROWS.
• Press ENTER to confirm your choice.
• The Playlist is now complete, and may be reviewed with the SCROLL ARROWS, or
auditioned with the PLAY button.
• Press ENTER to set the Playback Pointer to the currently displayed Step.
• To insert a new Step into the Playlist, use the SCROLL ARROWS to select the position
within the list, then press a HOT-KEY to add the new Step.
• To remove a Step from the Playlist, use the SCROLL ARROWS to select the Step, then
press CANCEL to remove it from the list. Press ENTER to confirm, or CANCEL.
• To append a Step to the end of the Playlist, SCROLL to the end of the list and press
additional HOT-KEYS to add additional Steps.
MENUS AND MENU OPTIONS
Default values are UNDERLINED. All settings are saved on disk and restored on power up.
Record Setup
Audio Input - ANALOG, AES/EBU XLR-3,
AES/SMPTE 75 OHM RCA, IEC 958 TYPE II RCA
Threshold (in dB) - OFF, -6, -12, -18, -24, -30, -36, -42, -48, -54, -60
