Appendix A: Cable description and NT8D81BA cable replacement Page 335 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
Table 57
NTMF94EA E - LAN, T - LAN and Serial Port cable connections
I/O Panel: P1 Signal Name P2, P3, P4 Color
P1-21 BSOUTB- P2-2 Red
P1-22 BDTRB- P2-4 Green
P1-25 SGND P2-5 Brown
P1-45 BSINB- P2-3 Blue
P1-46 BDCD- P2-1 Orange
P1-47 BDSRB- P2-6 Yellow
P1-9 SHLD GRND
P1-25 SHLD GRND
P1-43 SHLD GRND
P1-50 SHLD GRND
P1-23 RXDB+ P3-3 Green / White
P1-24 TXDB+ P3-1 White / Green
P1-48 RXDB- P3-6 Orange / White
P1-49 TXDB- P3-2 White / Orange
P1-18 RX+ P4-3 Green / White
P1-43 RX- P4-6 White / Green
P1-19 TX+ P4-1 Orange / White
P1-44 TX- P4-2 White / Orange
