Maintenance Page 331 of 378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
T:20 CardLAN enabled, waiting for Request Config.
Message.
Card is looking for an active leader by sending
bootp requests on the management LAN. If no
bootp response is received on the management
LAN, Leader 0 times out first and starts active
leader tasks. Leader 1 has a longer time out and
normally starts backup leader tasks when it
detects an active leader, otherwise Leader 1
times out and starts active leader tasks.
A Follower card sends bootp requests on the
management LAN continuously and never times
out. From the keyboard of a terminal attached to
the local maintenance port, enter +++ to escape
from bootp request mode and start ITG shell for
manual configuration.
BIOS Card is running the ROM BIOS.
The card detected no valid ITG Trunk software
image or the JKL escape sequence was entered
during startup from the keyboard of a terminal
connected to the local maintenance port.
If faceplate displays BIOS, it is not functioning as
an ITG trunk card.
T:21 CardLAN operational, A07 interface to Meridian 1
enabled, display now under ITG Trunk software
control.
ITG > shell is available for manual card
configuration.
T:22 ITG card is starting up the ITG ISL Trunk
application.
LDR Card is running active leader tasks.
Table 56
Faceplate maintenance display message summary (Part 3 of 4)
Normal
Code
Fault
Code
Description
