Page 322 of 378 Maintenance
553-3001-202 Standard 1.00 April 2000
Remove the card for two to three seconds and then reinstall it. If the failure
continues, you must replace the card. Use the following procedure to replace
the card:
1 Locate the node of the bad card:
a Open the ITG ISDN IP Trunks application in MAT.
b In the upper part of the IP Telephony Gateway - ISDN IP Trunk
window, click on the site name. All the cards in the node are listed
in the lower part of the window.
c Locate the card to be replaced in the lower window by card TN.
2 Disable the bad ITG card in LD 32 by using the DISI command.
3 If the card that is to be replaced is an 8-port NTCW80AA card,
disconnect the T-LAN Ethernet cable from the faceplate of the bad
card. Label the cable to identify that it is the T-LAN Ethernet
connection so that you can later reattach it to the replacement card.
If the card that is to be replaced is an 8-port NTCW80CA or a 24-port
NT9061AA card, disconnect the T-LAN Ethernet cable from the I/O
cable. Label the cable to identify that it is the T-LAN Ethernet
connection so that you can reinstall the cable on the replacement card.
Remove the bad ITG card from the Meridian 1.
4 Select Leader 0 or any ITG card in the node, from the lower window.
5 Select menu Configuration | Node | Properties in the IP Telephony
Gateway window.
6 Click the “Configuration” tab in the ITG Node Properties window.
7 In the “Configuration” tab, select the bad ITG card from the list of cards
in the node.
8 Change the MAC address to the MAC address of the replacement ITG
card. The MAC address is the “Motherboard Ethernet” address on the
faceplate label of the replacement ITG card.
9 Click “OK”.
10 Select Leader 0 or any ITG card in the node.
