Page 316 of 378 Maintenance
553-3001-202 Standard 1.00 April 2000
Table 54
Operational Measurement command
Command Description
resetOM
This command returns all Operational Measurement
parameters collected since last log dump, including:
• outgoing calls tried
• outgoing calls completed
• incoming calls tried
• total voice time
•total fax time
• outgoing packets discarded
• incoming packets out - of - sequence
• average packet delay
• average packet loss
• number of Fallback - to - PSTN calls
Table 55
DCHIP-only commands
Command Description
DCHenable
Enable the DCH application on the card.
DCHdisable
Disable the DCH application on the card.
DCHestablish
Establish the DCH link when it is in release mode.
DCHrelease
Release the DCH link when it is in establish mode.
DCHstatus
Display the DCH application state.
DCHmenu
This command allows the user to access the UIPC Debug
Menu. Once in passthru mode, the user has to “exit” the Debug
Menu, before issuing any other ITG Shell Commands.
dchipResTableShow
Available from ITG shell. Show the Followers associated with a
DCHIP.
