Page 308 of 378 Maintenance
553-3001-202 Standard 1.00 April 2000
Note: All ITG shell commands are case-sensitive.
Commands are grouped into eight categories, as shown in Tables 50-55.
Table 50
General purpose commands (Part 1 of 3)
Command Description
cardReset
Perform a warm reboot of the ITG card. The card has to be in
the OOS state to be able to use this command.
itgCardShow
Show card information.
ldrResTableShow
Show Backup Leader and Followers for a given Leader.
itgChanStateShow
Show state of channels (for example, busy or idle).
h323SessionShow
Show H323 session information for each channel.
itgMemShow
Show memory usage.
ifShow
Show detailed network interface information, including MAC
and IP addresses.
IPInfoShow
This command will return the following IP information:
• IP addresses (for both management and voice networks)
• default router (for both management and voice networks)
• subnet masks (for both management and voice networks)
• SNMP manager
cardStateShow
card state (that is Unequipped, Disabled, Enabled).
serialNumShow
Print out card serial number and PEC.
This command displays the same ITG card serial number that is
displayed from the Meridian 1 IDC command, and the Product
Engineering Code (PEC).
firmwareVersionShow
Print out firmware version number.
numChannelsShow Print out number of available channels.
numNodesInFallbackShow
List the IP addresses of the nodes that are in fallback to the
conventional voice circuit-switched network.
