Page 300 of 378 Maintenance
553-3001-202 Standard 1.00 April 2000
ITG0308
Address translation failure. Call is
released.
ITG0309
Unexpected DSP channel closed.
Channel is unusable.
ITG0310
Cannot open DSP channel.
ITG0311
Unable to get response from
Follower card. Card can be
unplugged.
ITG0312
Unable to push BOOTP tab file to
Backup Leader.
ITG0350
Gatekeeper RAS reject threshold
exceeded.
ITG0351
Cannot open Gatekeeper
configuration file. Using default
settings.
Major Alarms – Immediate intervention
required
These alarms indicate an irrecoverable failure of
the ITG card. Normal operation can only be
restored through manual intervention.
ITG0400
Fatal self-test failure. Card is out of
service. A fatal self-test diagnostic
error was found.
ITG0401
Reboot threshold exceeded.
Manual intervention required.
ITG0402
Ethernet voice port failure. T - LAN
problem or cable removed.
ITG0403
Ethernet management port failure.
E - LAN problem or cable removed.
Table 44
ITG Trunk 2.0 alarms (Part 4 of 6)
Alarm Description Fault Clearing Action
