Description
553-3001-202 Standard 1.00 April 2000
Ordering rules and guidelines
Ordering rules for ITG ISL Trunk node initial configuration
Initial configuration of an ITG ISL Trunk node requires either:
• one NTZC44AA ITG ISDN Large Systems package, or
• one NTZC44BA ITG ISDN Small Systems package,
as appropriate for your system. These packages include all Meridian 1
components needed for a single-card node, except for the cables that provide
interface to the MSDL and SDI/DCH cards. DCH interface cables are
included:
• NTND26AA (Large Systems)
• NTAK19FB and NTWE04AD (Small Systems)
The following packages are required for ITG ISL Trunk:
• ISDN Base (ISDN) package 145
• ISDN Signaling Link (ISL) package 147
MAT 6.6 or OTM 1.1 is required and must be ordered separately. The MAT
Alarm Notification application is not included with MAT 6.6 and must be
ordered separately.
For MSDL and DCHIP cards that reside in the same Large System UEM
equipment row, order:
• NTND26 MSDL DCH cable in sufficient length to reach from the MSDL
to the I/O Panel of the IPE module that contains the DCHIP.
For MSDL and DCHIP cards that reside in different Large System UEM
equipment rows in a multi-row Large System, order:
• NTMF04BA MSDL DCH Extender (50 ft.) cable to reach between the
I/O Panels of the two UEM equipment rows.
For SDI/DCH and DCHIP cards that reside in different Small System
cabinets, order:
• NTWE04AC Inter cabinet cable (NTCW84KA to SDI/DCH cable-10 ft.)
