Description Page 25 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
10 ft. Inter cabinet cable NTCW84KA to SDI/DCH cable NTWE04AC
A0794156
1 ft. Intra cabinet cable NTCW84KA to SDI/DCH cable NTWE04AD
A0794157
Shielded four-port SDI/DCH cable for the NTAK02BB
SDI/DCH card (included in Small System package)
NTAK19FB
A0403450
PC Maintenance cable (for faceplate RS232
maintenance port to local terminal access)
NTAG81CA
A0655007
Maintenance Extender cable NTAG81BA
Large Systems filter connector
50 pin I/O Panel Filter Connector Block with ITG specific
filtering for 100BaseTX (included in Large Systems
package)
NTCW84JA
A0783483
Backplane to I/O Panel ribbon cable assembly
compatible with NTCW84JA I/O Panel Filter Connector
Block with ITG-specific filtering for 100BaseTX T-LAN
connection (replaces NT8D81BA Backplane to I/O Panel
ribbon cable assembly equipped with non-removable
Molded Filter Connectors)
NT8D81AA
A0359946
Documentation
Meridian Internet Telephony Gateway (ITG) Trunk
2.0/ISDN Signaling Link NTP
P0906569
PC Cards
C7LIU DCH PC Card with Layer 2 DCH Software NTWE07AA
A0794155
ITG Trunk 2.0 24-Port Software Upgrade on 8Mb ATA
Flash Rom PC Card
NT0963AA
A0786148
ITG Trunk 2.0 8-Port Software Upgrade on 8Mb ATA
Flash ROM PC Card
NT0962AA
A0786147
Table 2
Hardware components for Meridian 1 ITG ISL Trunk (Part 3 of 3)
Component Product codes
