Description Page 23 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
List of ITG ISDN components
Table 2 lists ITG ISDN components.
Note 1: MAT 6.6 or later, or OTM 1.0, including the Common Services,
Alarm Management, and ITG ISDN applications, is a prerequisite and
must be ordered separately.
Note 2: Nortel Networks Netgear RM356 Modem Router or equivalent
is required for remote support and must be ordered separately from retail
outlets.
Note 3: You must inspect the IPE module to determine if it is equipped
with non-removable Molded Filter Connectors on the I/O Panel. For
Large Systems manufactured during the period of 1998-1999 and
shipped in North America, the IPE modules have the NT8D81BA
Backplane to I/O Panel ribbon cable assembly with a non-removable
Molded Filter Connector. The NT8D81BA is compatible with 10BaseT
T-LAN, but if you require a 100BaseT T-LAN, you need to replace it
with the NT8D81AA Backplane to I/O Panel ribbon cable assembly.
Table 2
Hardware components for Meridian 1 ITG ISL Trunk (Part 1 of 3)
Component Product codes
System Packages
ITG ISDN Signaling Trunk Large Systems Package
including D-Channel (NT0961AA 24-Port ITG ISL Trunk
with RTU and pre-installed software, I/O cables, DCH
PC card, 50-pin I/O Panel Filter connector with ITG
specific filtering for 100BaseTX, and NTP)
NTZC44AA
A0786079
ITG ISDN Signaling Trunk Small Systems (Option 11C)
Package including D-Channel (ITG Trunk 2.0 card with
RTU license and pre-installed software that supports 24
ports, required cables, DCH PC card, and NTP)
NTZC44BA
A0786080
ITG ISDN Signaling Trunk Small and Large Systems
Package without DCH PC Card or NTP
NTZC45AA
A0786081
