Install and configure ITG ISL Trunk node Page 221 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
Note: Disable ITG Trunk cards when transmitting card properties or
new software.
Use the MAT Maintenance Windows, the MAT System Passthru terminal, or
use a Meridian 1 system management terminal directly connected to a TTY
port on the Meridian 1.
Wait for the NPR0011 message, which indicates that
all units on each card are disabled.
Use the overlay 32 DISI command to
disable the ITG cards when idle. In the IP Telephony Gateway - ISDN IP
Trunk Main window, select
View | Refresh
and verify that the card status is
showing “Disabled”. If the card status shows “unequipped,” configure the
card in LD14.
1 Select the ITG Trunk node for which you want to transmit properties
from the list in the upper part of the window.
2 Select Leader 0 from the list in the lower part of the window.
3 In the IP Telephony Gateway - ISDN IP Trunk Main window, select
menu Configuration | Synchronize | Transmit.
4 Leave the radio button default setting of Transmit to selected nodes.
Check the Card Properties and Dialing Plan check boxes.
5 Click the Start Transmit button.
6 Monitor progress in the Transmit Control window. Confirm that the
Card Properties and Dialing Plan are transmitted successfully to all
ITG ISL Trunk cards, which are identified by TNs.
7 When the transmission is complete, click the Close button.
8 Use the overlay 32 ENLC command to enable the ITG cards in the
node.
9 In the IP Telephony Gateway - ISDN IP Trunk Main window, select
View | Refresh. The card status should now show “Enabled.”
10 Verify the TN, management interface MAC address, IP addresses, and
D-Channel for each ITG card. Compare the configuration data with the
data on the ITG Installation Summary Sheet.
Once the Card Properties and Dialing Plan have been successfully
transmitted, the new Card Properties and Dialing Plan are automatically
applied to each card. The ITG node is now ready to make test calls provided
that the ITG ISL Trunks and the ESN data have been configured on the
Meridian 1.
