Description
553-3001-202 Standard 1.00 April 2000
Table 1
Software packages for Meridian 1 ITG ISL Trunk
Package Package number Notes
Basic Alternate Route Selection
(BARS) or Network Alternate
Route Selection (NARS)
57 or 58 Required
ISDN Base (ISDN) 145 Required
ISDN Signaling Link (ISL) 147 Required
MSDL 222 (large systems) Required
QSIG Interface (QSIG) 263 (large systems) Optional
QSIG GF Transport (QSIG GF) 305 (large systems) Optional
Advanced ISDN Network
Services (NTWK)
148 Optional
Coordinated Dialing Plan
(CDP).
59 Optional
Flexible Numbering Plan (FNP) 160 Optional
