Install and configure ITG ISL Trunk node Page 189 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
TOD Time of Day Schedule
If required, turn off ITG route during peak traffic
periods on the IP data network
FRL Facility Restriction Level
Set FRL appropriately to control access to the ITG
ISL Trunk route.
DMI 0 Do not use a Digit Manipulation table in the RLB
entry for the ITG ISL Trunk route.
For ESN translations that are not used for
non-call-associated signalling, digit manipulation
can be defined on the ITG ISL Trunk node dialing
plan in the Digits dialed tab.
SBOC
RRA
Step Back on Congestion.
Re-route all. Enter RRA at the SBOC prompt to
enable Fallback to alternate circuit-switched trunk
route
...
Table 38
LD 87 - Configure the Coordinated Dialing Plan (CDP)
Prompt Response Description
REQ NEW Add new data.
FEAT CDP Coordinated Dialing Plan.
CUST xx Customer number.
TYPE DSC
TSC
Distant Steering Code.
Trunk Steering Code.
...
RLB xx Route List Entry created in Overlay 86.
...
Table 37
LD 86 - Configure route list block with Step Back on Congestion on ISDN (Part 2 of 2)
Prompt Response Description
