Install and configure ITG ISL Trunk node Page 181 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
CTYP Call type for outgoing call dialed with the route
access code (ACOD).
Set to appropriate call type for ITG Trunk node
numbering plan in order to make test calls using
ACOD.
INAC (NO) YES INAC stands for automatic insertion of the ESN
access code on incoming calls, according to ISDN
call types corresponding to NPA NXX INTL SPN
LOC, etc.
Note:
Using INAC=YES can simplify the configuration of
the ESN RLBs and DGT. It is recommended for MCDN
features with non-call-associated signalling, e.g. NMS,
NACD, NRAG.
Note:
By default, the INAC feature puts all ESN call
types except for CDP under AC1. If any call types must
go under AC2 for INAC, use LD15 to configure them at
the AC2 prompt at the customer data block.
...
ICOG
IAO
Incoming and/or Outgoing trunk.
Incoming and Outgoing.
SRCH LIN Linear search method.
See Note 1.
SIGO (STD)
ESN5
Standard signaling arrangement
ESN 5 signaling
Note:
Unless you are using ESN5, SIGO (outgoing
signaling protocol) must be set to STD.
Note:
If SIGO equals ESN5:
Select SL1ESN5 from the pull-down list in the Protocol
field in the MAT Node Properties configuration tab.
Select SL1ESN5 from the pull-down list in the Remote
Capabilities field in the MAT Node Dialing plan General
tab for each destination node that uses ESN5.
CNTL YES
Table 34
LD 16 - Configure the ITG ISL TIE Trunk route data block (Part 3 of 4)
Prompt Response Description
