Install and configure ITG ISL Trunk node Page 179 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
Note: You must configure Trunk routes as TIE routes..
Table 34
LD 16 - Configure the ITG ISL TIE Trunk route data block (Part 1 of 4)
Prompt Response Description
REQ NEW Add new data.
TYPE RDB Route Data Block. Configuration parameters that
apply to all trunks in this route.
CUST xx Customer number associated with this route, as
defined in LD 15.
ROUTE xxx Route Number, where:
x = 0-511
DES ITG ISL TRUNK 16-character designator is “ITG ISL TRUNK”
Specific description if more than one ITG Trunk
route exists.
...
TKTP
TIE
Trunk Type.
The trunk type for ITG ISL trunks must be set to
TIE.
SAT (NO) YES Satellite control (SAT) must be set to NO to enable
Trunk Optimization before answer (TRO) and
Trunk Anti-Tromboning (TAT).
For ITG Trunk 2.0 fallback to circuit-switched
trunks does not depend on SAT=YES.
...
DTRK
(NO)
Digital Trunk Route.
ITG ISL Trunks are analog only. They do not
support circuit-switched data from MCA or ISDN
BRI terminal adaptors.
ISDN YES Integrated Services Digital Network.
