Install and configure ITG ISL Trunk node Page 175 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
IFC
SL1
ESGF
ISGF
Interface type for D-channel:
Meridian Customer Defined Network (MCDN)
ESIG interface with GF platform (QSIG)
ISIG interface with GF platform (QSIG)
Note 1:
The ESGF and ISGF responses are allowed if
the QSIG and QSIG GF packages are both equipped.
Note 2:
The IFC entry must match the protocol entered
in MAT’s ITG Node Properties, Card Configuration,
Protocol pull - down menu.
ISLM xxx Integrated Service Signaling Link Maximum
CHIDs, where:
x = 1-382
ISLM is the maximum number of ISL trunks
controlled by the D-channel. There is no default
value.
BPS (64000) 64000 is default, and is required for the ITG ISL
Trunk DCHIP.
PARM (RS422 DTE) The RS-422 parameters are established with
switch settings on the MSDL card. This prompt is
used to verify those settings prior to enabling the
card.
RCAP
ND2
Remote Capabilities
Network Name Display type 2 signaling. All nodes
must use same RCAP.
...
SIDE (USR) Meridian 1 MSDL acts as User side of ISL.
ITG Trunk DCHIP card acts as the Network side of
ISL.
Table 31
LD 17 - Configure the ISL D-channel for the ITG DCHIP card (Large Systems) (Part 2 of 3)
Prompt Response Description
