Install and configure ITG ISL Trunk node Page 167 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
Install shielded voice interface (T-LAN) cable
You must use Shielded Category 5 cable to connect to the E-LAN, T-LAN
ports on the NTCW84KA cable. To conduct a ground loop test, turn to
page 349 and follow the test procedure.
For DCHIP cards
Connect a shielded Category 5 LAN cable from the T-LAN hub to the
RJ45 coupler on the NTCW84KA T-LAN connector.
For non-DCHIP cards
Connect a shielded Category 5 LAN cable from the T-LAN hub to the
RJ45 coupler on the NTMF94EA T-LAN connector.
Note:
When connecting the ITG card to the T-LAN, the link status
LED on the ITG card faceplate associated with the voice interface will
light green when the connection is made, and the link status LED on
the hub port will also light green when connected to the ITG card.
Install shielded management interface (E-LAN) cable
For DCHIP cards
Connect a shielded Category 5 LAN cable from the E-LAN hub to the
RJ45 coupler on the NTCW84KA E-LAN connector.
For non-DCHIP cards
Connect a shielded Category 5 LAN cable from the E-LAN hub to the
RJ45 coupler on the NTMF94EA E-LAN connector.
Note:
There are no E-LAN network status LEDs for the management
interface on the ITG Trunk card. When connected to the ITG card
management interface, the port status LED indicator on the E-LAN hub
lights green to indicate a good connection.
