Install and configure ITG ISL Trunk node Page 165 of
378
ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
Figure 24
NTCW84KA E-LAN, T-LAN, DCH and serial cable
Shielded RJ-45 Cable
Mountin
g
Screw
Shielded 25-Pair
Matin
g
Coupler
Shielded RJ45
Amphenol Connector
To Hub
9 Pin D-Sub
Female
Ferrite
To Hub
15 Pin D-Sub
Female
