ITG Trunk 2.0 ISDN Signaling Link (ISL) Description, Installation and Operation
234
Install and configure ITG ISL Trunk node
This section describes how to add a new ITG 2.0 trunk node in MAT, how to
install the cards and cables, and how to configure and transmit the node
properties.
Before you begin
1 Install MAT 6.6 or later, or install OTM 1.0. Make sure you install the
ITG ISDN IP Trunk and Alarm Management applications.
2 Upgrade Meridian 1 X11 software to Release 25A or later. ITG
requires packages 145 (ISDN) and 147 (ISL). Install additional
software packages, such as Package 148 NTWK, as required for
advanced ISDN features.
3 Check that required LAN and WAN networking equipment and cables
are installed. For networking equipment requirements, turn to “ITG
Engineering Guidelines” on page 71. The ITG Trunk card requires
shielded cables.
4 ITG Trunk card (NT0961AA) DCHIP PC Card (NTWE07) and cable
assemblies required for your site.
5 For Meridian 1 Large Systems, ITG ISL (NT6D80). For Meridian 1
Small Systems, ITG ISL Trunk 2.0 requires at least one available port
on an SDI/DCH card (minimum vintage NTAK02BB). Be sure
D-channel cards have required cables.
6 Check that the customer site has a Nortel Networks Netgear RM356
Modem Router (or equivalent) on the E-LAN. The modem router
provides remote support access to ITG Trunk and other IP-enabled
Nortel Networks products on the Meridian 1 site. See Appendix D:
“Configure a Netgear RM356 modem router for remote access” on
page 359 for more information on routers.
