Page 12 of
378
Contents
553-3001-202 Standard 1.00 April 2000
Add Dialing Plan entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Transmit configuration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Add an ITG ISL Trunk node on MAT by retrieving an existing node 262
Retrieve and add an ITG ISL Trunk Node for
administration purposes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
Retrieve and add an ITG ISL Trunk Node for maintenance
and diagnostic purposes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Configuration audit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Retrieve ITG configuration information from the ITG node . . . . . 266
Schedule and generate and view ITG OM reports . . . . . . . . . . . . . 268
Backup and restore operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Alarm Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Meridian 1 system commands - LD 32 . . . . . . . . . . . . . . . . . . . . . . . . 270
Disable the indicated ITG card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Disable the indicated ITG card when idle . . . . . . . . . . . . . . . . . . . . 273
Disable an indicated ITG port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Enable an indicated ITG card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Enable an indicated ITG port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Display ITG card ID information . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Display ITG card status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Display ITG card port status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
OA&M using the ITG shell CLI and overlays . . . . 275
ITG Shell OA&M procedure summary . . . . . . . . . . . . . . . . . . . . . . . . 275
Access the ITG shell through a maintenance port or Telnet . . . . . . . . 276
Connect a PC to card maintenance port . . . . . . . . . . . . . . . . . . . . . 276
Telnet to an ITG card through the MAT PC . . . . . . . . . . . . . . . . . . 277
Change the default ITG shell password to maintain access security 278
Reset the default ITG shell password . . . . . . . . . . . . . . . . . . . . . . . 279
Download the ITG operational measurements
through the ITG shell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Reset the operational measurements . . . . . . . . . . . . . . . . . . . . . . . . 281
Display the number of DSPs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Display ITG Node Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Transfer files through the command line interface . . . . . . . . . . . . . 282
Upgrade ITG card software from the command line interface . . . . 284
