Manual

Mounting
2.3
20
Wall mounting
is equipped with two hangings on the back side for wall mounting. For
drilling holes to the wall could be used drill pattern in QuickStart.
Power Supply Connection
is fed with 10-16V DC. Where a source other than the included power
supply adapter is used, the voltage range and polarity shown on the 
power supply connector have to be maintained.
Warning
 Do not activate the power supply until the antenna is connected to
to avoid the GSM module damage.
Figure 2.4
Zavěšení
2N
®
SmartGate
na zeď
