2.3 Mounting
External Antenna Connection
Screw the antenna enclosed into the SMA antenna connector.
Caution
 Tighten the antenna connector gently with your hand  never use
wrenches!
Note
 The antenna enclosed has a sufficient gain for trouble-free operation in
normal conditions. If the GSM signal is poor or you want to place your
antenna separately from SmartGate, you can use an antenna with an
SMA-connector terminated cable. The antenna should be mounted
vertically.
 The Antenna shall be located within the same building as the main equipment.
 Technical Parameters”.
SIM Card Installation
 card and close it
properly.
Cautions
 
network supported by your version.
 Select the required GSM provider and SIM card services, such as call
forwarding, call barring, preferred networks, SMS service centre, etc. in
your mobile phone before inserting your SIM card in 2N
®
SmartGate.
Figure 2.3
SIM Card
Installation
